Xerox WorkCentre 5230 User Manual

February, 2008
3-22
WorkCentre 5225, 5230
Launch Version
Image Quality
IQS13 Background Specification
Procedure
Use Side A of the Standard Test Pattern.
Compare images of the test pattern,(Figure 1) made from the
document glass, with the visual scale,82P448.
The background of the images must not be darker than the
reference area “C” (Figure 1).
Figure 1 Test Pattern(j0st3215)

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
