February, 2008
2-561
WorkCentre 5225, 5230
078-500 , 078-900
Status Indicator Raps
Launch Version
078-500 Write to HCF-ROM error detection (During DLD
method) RAP
An error has occurred during the process of writing data to the HCF-ROM. (During DLD method)
Procedure
Retry job. If retry failed, replace the HCF-ROM and perform VerUP operation on the DLD method
again.
078-900 HCF Feed Out Sensor Static Jam RAP
BSD-ON: 8.9
The tray 6 Feed Out Sensor static jam.
Initial Actions
• Clear any jam and switch the power off then on.
• Check for out-of-spec paper.
• Paper Path for a foreign object/burr/piece of paper
Procedure
Execute Component Control [078-101 Tray 6 Feed Out Sensor]. Move the actuator of the Tray
6 Feed Out Sensor.
The display changes.
YN
Go to 8.8 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Feed Out Sensor PF67-2 to HCF PWB PF01-2
• Tray 6 Feed Out Sensor PF67-1 to HCF PWB PF01-3
• Tray 6 Feed Out Sensor PF67-3 to HCF PWB PF01-1
If OK, replace the Tray 6 Feed Out Sensor (PL 18.7) then the HCF PWB (PL 18.8).
Execute Component Control [078-007 Tray 6 Takeaway Motor: 640mm/s]. There is opera-
tion noise from the Tray 6 Takeaway Motor.
YN
Check the wire-wound resistance of Pre Reg. Motor is approx. 0.8 ohms at the measurement
points below.
• JF57-3 to pins 1/2
• JF57-4 to pins 5/6
If OK, go to 7.14 BSD and troubleshoot the Tray 6 Takeaway Motor circuit.
Execute Component Control [089-002 REgistration Clutch. Registration Clutch operates
YN
Go to 8.7 BSD and check the Registration Clutch for an open.
Check the following:
• Drive gears for wear/breakage
• HCF and IOT for a poor docking
• HCF Transport Belt for poor tension
• HCF Transport Roll for dirt/paper particles/wear/a poor rotation
• HCF Takeaway Rolls 1-3 for dirt/ paper particles/wear/a poor rotation
• HCF Exit Roll for dirt/ paper particles/wear/a poor rotation
• If the results of the above checks are OK, replace HCF PWB (PL1.8).
To Next Page
