WorkCentre 5225, 5230
072-101
Status Indicator Raps
Launch Version
072-101 Tray 2 MisFeed JAM RAP
BSD-ON:7.8/8.2
After the Tray 2 Feed/Lift Motor turned On, the Tray 2 Feed Out Sensor did not turn On within
the specified time.
Initial Actions
• Power OFF/ON
Procedure
Check the Transport Roll for wear and paper powder. The Transport Roll is ok.
YN
Replace the Transport Roll.
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Execute Component Control[071-100 Tray 2 Feed Out Sensor]. Actuate the Tray 2 Feed Out
Sensor (PL 2.5) with paper.
The display changes.
YN
Check the connections of P/J105, P/J608 and P/J410. P/J105, P/J608 and P/J410
are connected correctly.
YN
Connect P/J105, P/J608 and P/J410.
Check the wire between J105 and J410 for an open circuit or a short circuit (BSD 8.2).
The wire between J105 and J410 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P410-6 (+) and GND (-) (BSD 8.2 Flag 2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P410-8 (+) and GND (-) (BSD 8.2 Flag 1).
Actuate the Tray 2 Feed Out Sensor (PL 2.5) with paper. The voltage changes.
YN
Replace the Tray 2 Feed Out Sensor (PL 2.5).
Replace the MCU PWB (PL 9.1).
Execute Component Control[071-008 Tray 2 Feed/Lift Motor ON]. The Tray 2 Feed/Lift Motor
(PL 2.3) can be heard.
YN
Check the connections of P/J202, P/J602 and P/J409. P/J202, P/J602 and P/J409
are connected correctly.
YN
Connect P/J202, P/J602 and P/J409.
Remove the Tray 2 Feed/Lift Motor (PL 2.3) and the Tray 1 Feed/Lift Motor (PL 2.3).
Replace the Tray 2 Feed/Lift Motor with the Tray 1 Feed/Lift Motor.
Execute Component Control[071-008 Tray 2 Feed/Lift Motor ON]. The Tray 1 Feed/Lift
Motor (PL 2.3) can be heard.
YN
Return the Tray 1 Feed/Lift Motor to its original position.
Check the wire between J202 and J409 for an open circuit or a short circuit (BSD 7.8
Flag 1).
The wire between J202 and J409 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the MCU PWB (PL 9.1).
Return the Tray 1 Feed/Lift Motor to its original position.
Replace the Tray 2 Feed/Lift Motor (PL 2.3).
Replace the MCU PWB (PL 9.1).
A
A
