Xerox WorkCentre 5230 User Manual

February, 2008
6-154
WorkCentre 5225, 5230
Product Specs., Common Tools
Launch Version
General Procedures
IIT/DADF Specifications
Common Tools
Table 4 DADF Specifications
Document Size: Platen Max size: 297 x 420 mm, 11 x 17 in.
Max scannable area: 297 x 420 mm
Document Size: DADF 5.5” x 8.5” (A5) LEF to 11” x 17” SEF (A3)
Max: 297 x 432 mm
Min: 139.7 x 210 mm
Document Weight: DADF Min: 50 gsm/16lb
Max: 128 gsm/32lb (Duplex mode)
Document Capacity: DADF 50 sheets 38 gsm to 120 gsm.
R/E Capability: Variable Percentages: 25% to 400% in 1% increments
Preset Percentages:
• 25%
• 50%
• 64.7% (11 x17 in. to 8.5 x 11 in.)
• 78.5% (8.5 x 14 in. to 8.5 x 11 in.)
• 100%
• 129.4% (8.5 x 11 in. to 11 x17 in.)
• 220% (3.5 x 5 in. to 8.5 x 11 in.)
• 400%
Presets can be changed in Tools mode.
Table 1 Common Tools
Description Part Number
Screw Driver (-) 3 x 50 600T 40205
Screw Driver (+) 6 x 100 600T 01989
Screw Driver (+) NO.1 499T 00356
Stubby Driver (+) (-) 600T 40210
Screw Driver (-) 100MM 499T 00355
Spanner and Wrench 5.5 x 5.5 600T 40501
Spanner and Wrench 7x 7 600T 40502
Hex Key Set 600T 02002
Box Driver 5.5MM 600T 01988
Side Cutting Nipper 600T 40903
Round Nose Pliers 600T 40901
Digital Multi-meter Set 600T 02020
Interlock Cheater 600T 91616
Silver Scale 150MM 600T 41503
CE Tool Case 600T 01901
Magnetic Screw Pick-up Tool 600T 41911
Scriber Tool 600T 41913
Magnetic pickup 600T 41911
Loupe 600T 42008
Flash Light 600T 01824
Brush 600T 41901
Tester Lead Wire (red) 600T 09583
Tester Lead Wire (black) 600T 02030

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
