Xerox WorkCentre 5230 User Manual

February, 2008
7-3
WorkCentre 5225, 5230
7.1.1
Wiring Data
Launch Version
7.1.1 Plug/Jack Locations
How to use the Plug/Jack Location List
The Plug/Jack Location List below is provided to locate plugs, jacks, or other terminating
devices. Locate the desired termination device in the first column (Connector Number) of the
list. Refer to the second column (Figure Number) to determine the figure number of the electri
-
cal termination device. Refer to the (Item Number) column to determine the item number in the
adjacent Figure Number column. The fourth column supplies the title of the Figure.
NOTE: Connectors numbered “CN” and “FS” are listed after the “P and J” connectors.
Plug/Jack Location List
Table 1 Plug/Jack List (A-Finisher)
Connector
Number
Figure
Number
Item
Number
Figure Title
P/J8700 Figure 2 2 A-Finisher PWB Location
P/J8701 Figure 2 1 A-Finisher PWB Location
P/J8702 Figure 2 11 A-Finisher PWB Location
P/J8703 Figure 2 10 A-Finisher PWB Location
P/J8704 Figure 2 13 A-Finisher PWB Location
P/J8705 Figure 2 12 A-Finisher PWB Location
P/J8706 Figure 2 8 A-Finisher PWB Location
P/J8707 Figure 2 3 A-Finisher PWB Location
P/J8708 Figure 2 17 A-Finisher PWB Location
P/J8709 Figure 2 16 A-Finisher PWB Location
P/J8710 Figure 2 9 A-Finisher PWB Location
P/J8711 Figure 2 4 A-Finisher PWB Location
P/J8721 Figure 3 2 A-Finisher Bottom Location
P/J8722 Figure 3 1 A-Finisher Bottom Location
P/J8723 Figure 3 6 A-Finisher Bottom Location
P/J8724 Figure 1 1 A-Finisher Front Location
P/J8725 Figure 3 11 A-Finisher Bottom Location
P/J8726 Figure 1 7 A-Finisher Front Location
P/J8727 Figure 1 9 A-Finisher Front Location
P/J8728 Figure 1 8 A-Finisher Front Location
P/J8729 Figure 1 6 A-Finisher Front Location
P/J8730 Figure 1 2 A-Finisher Front Location
P/J8731 Figure 1 4 A-Finisher Front Location
P/J8732 Figure 1 3 A-Finisher Front Location
P/J8733 Figure 2 14 A-Finisher PWB Location
P/J8734 Figure 2 15 A-Finisher PWB Location
P/J8735 Figure 1 5 A-Finisher Front Location
P/J8736 Figure 3 5 A-Finisher Bottom Location
J8737A Figure 3 9 A-Finisher Bottom Location
J8737B Figure 3 9 A-Finisher Bottom Location
J8738A Figure 3 10 A-Finisher Bottom Location
J8738B Figure 3 10 A-Finisher Bottom Location
P/J8739 Figure 2 7 A-Finisher PWB Location
P/J8740 Figure 2 5 A-Finisher PWB Location
P/J8741 Figure 2 6 A-Finisher PWB Location
J8742A Figure 3 7 A-Finisher Bottom Location
J8742B Figure 3 8 A-Finisher Bottom Location
CN3 Figure 3 4 A-Finisher Bottom Location
CN4 Figure 3 3 A-Finisher Bottom Location
Table 1 Plug/Jack List (A-Finisher)
Connector
Number
Figure
Number
Item
Number Figure Title
