Xerox WorkCentre 5230 User Manual

February, 2008
2-577
WorkCentre 5225, 5230
093-925, 093-926
Status Indicator Raps
Launch Version
093-925 Toner K Crum Data Broken Failure
BSD-ON:9.1
Initial Actions
• Ensure that the Black Toner Cartridge is seated correctly.
• Ensure that the Toner Cartridge Door is closed.
Procedure
Fault codes 093-950 (Y), 093-951 (M), and 093-952 (C) are also present on the UI.
YN
Replace the Black Toner Cartridge (PL 4.1).
Replace the Toner CRUM (Toner Cartridge Door) (PL 4.2).
If the fault codes are still present, replace the MCU PWB (PL 9.1).
093-926 Toner K Crum Data Mismatch Failure
BSD-ON:9.1
Initial Actions
• Ensure a Black Toner Cartridge is installed in the Black position in the Rotary
• Ensure the correct toner cartridge for this product is installed
• Ensure that the Black Toner Cartridge is seated correctly.
• Ensure that the Toner Cartridge Door is closed.
Procedure
Fault codes 093-960 (Y), 093-961 (M), and 093-962 (C) are also present on the UI.
YN
Replace the Black Toner Cartridge (PL 4.1).
Replace the Toner CRUM (Toner Cartridge Door) (PL 4.2).
If the fault codes are still present, replace the MCU PWB (PL 9.1).

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
