Xerox WorkCentre 5230 User Manual

February, 2008
2-548
WorkCentre 5225, 5230
077-113 , 077-114
Launch Version
Status Indicator Raps
077-113 IOT Exit Sensor OFF JAM Straight RAP
BSD-ON:10.3/10.4
After the Exit 2 Sensor turned On, the Exit 2 Sensor did not turn Off within the specified time.
Initial Actions
• Power OFF/ON
Procedure
Check the installation of the Exit 2 Module. The Exit 2 Module is installed correctly.
YN
Install the Exit 2 Module correctly.
Check the Transport Roll for wear and paper powder. The Transport Roll is ok.
YN
Replace the Transport Roll.
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Execute Component Control [071-110 Exit 2 Sensor]. Actuate the Exit 2 Sensor (PL 6.4) with
paper.
The display changes to H.
YN
Check the wire between P/J112 and P/J434 for an open circuit or a short circuit (BSD
10.3 Flag 1/Flag 2).
The wire between J112 and J434 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Exit 2 Sensor (PL 6.4). If the problem persists, replace the Exit PWB (PL
9.1).
Execute Component Control [047-023 Exit 2 Motor ON]. The Exit 2 Motor (PL 6.4) can be
heard.
YN
Check the wire between P/J208 and P/J433 for an open circuit or a short circuit (BSD
10.4 Flag 1).
The wire between J208 and J433 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Exit 2 Motor (PL 6.4) between J208-1 and each point of
J208-2/3/4/5 (BSD 10.4 Flag 2).
The resistance is approx. 10Ohm.
YN
Replace the Exit 2 Motor (PL 6.4).
Replace the Exit 2 Motor (PL 6.4). If the problem persists, replace the Exit PWB (PL 9.1).
Replace the Exit PWB (PL 9.1).
077-114 Exit 2 Sensor Static JAM RAP
BSD-ON:8.7/9.3
Paper remains on the Exit 2 Sensor.
Initial Actions
• Power OFF/ON
Procedure
Execute Component Control [071-110 Exit 2 Sensor]. Actuate the Exit 2 Sensor (PL 6.4) with
paper.
The display changes to H.
YN
Check the wire between P/J112 and P/J434 for an open circuit or a short circuit (BSD
10.3 Flag 1/Flag 2).
The wire between J112 and J434 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Exit 2 Sensor (PL 6.4). If the problem persists, replace the Exit PWB (PL
9.1).
Replace the Exit PWB (PL 9.1).
