Xerox WorkCentre 5230 User Manual

February, 2008
6-153
WorkCentre 5225, 5230
Product Specs.
General Procedures
Launch Version
Product Codes
Component Weights
Paper Capacities
Copy Speed
• B/W (plain paper; simplex; fed from Tray 1)
– Letter size LEF: 25/30 ppm
– Letter size SEF: 20/22 ppm
– Legal size 8.5x14 SEF
Simplex: 16/19 ppm
Duplex: 10/12 ppm
– A3/11x17 SEF
Simplex: 14/16 ppm
Duplex: 9/11 ppm
FCOT/FPOT
First Copy Output Time (original on platen); 8.5” x 11” (A4); Tray 1;
• 4.3 sec. or less.
Voltage Requirements
• Single phase (two wires plus ground)
• 110 - 127 VAC/60 Hz (99 - 135 VAC, 50/60 +/- 3 Hz)
• 220 - 240 VAC/50 Hz (198 to 254 VAC, 50/60 +/- 3 Hz)
Power Consumption (5 minute average)
• Machine Running: 1.33 kVA - NASG; 1.92 kVA ESG max.
• Off Mode 1.5W~2.4W (Reference)
Environmental Data and Requirements
Ambient Temperature and Humidity requirement:
• Minimum: 10º C/50ºF at 15% humidity
• Maximum: 32º C/90ºF at 70% (28º C/82ºF at 85% humidity) humidity
Table 1 Product Codes WorkCenter 5225/5230
No. Item Product Code
1 WorkCenter 5225/5230 -
2 WorkCenter 5222 -
3 WorkCenter 5225/5230 DADF 120V -
4 WorkCenter 5225/5230 DADF 220V -
5 2TM -
6 TTM -
7 Label for WorkCenter 5225/5230 -
8 Label for WorkCenter 5222 -
9 A Finisher 120V -
10 A Finisher XC 220V -
11 SB Finisher 120V -
12 SB Finisher 220V -
Table 2 Component Weights
Component Weight (approx.)
DC (Platen) 64 kg (132 lb.)
IIT and Platen 15 kg (33 lb.)
2 Tray Module 23 kg (51 lb.)
Tandem Tray Module 31 kg (68 lb.)
Exit2 2 kg (4 lb.)
Duplex Module 1.8 kg (4 lb.)
HCF 29 kg (xx lb.)
DADF 9 kg (20 lb.)
SB Finisher 27 kg (66 lb.)
A Finisher 11.3 kg (xx lb.)
Table 3 Paper Capacities
Specification Paper Trays 1 - 4 Tray 5 (Bypass)
Paper Sizes
• Min: 139.7W x 182L
• Max: 297W x 432Lmm
Paper
• Min: 89W x 98.4L mm (postcard)
• Max: 297W x 431.8L mm/12 x 19 in.
Paper Weights Range: 60 - 216 gsm (Tray 2,
3, 4)
Tray 1: 60 - 105 gsm
Range: 60 - 216 gsm
Capacities 24 lb.
(90 gsm)
TTM: 3000 sheets total:
• Tray 1: 500 sheets
• Tray 2: 500 sheets
• Tray 3: 800 sheets
• Tray 4: 1200 sheets
2TM: 2000 sheets total:
• Tray 1: 500 sheets
• Tray 2: 500 sheets
• Tray 3: 500 sheets
• Tray 4: 500 sheets
100 sheets
Table 3 Paper Capacities
Specification Paper Trays 1 - 4 Tray 5 (Bypass)

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
