February, 2008
2-562
WorkCentre 5225, 5230
078-940, 078-941
Launch Version
Status Indicator Raps
078-940 HCF Paper Misfeed RAP
BSD-ON:8.9
There is a problem with one of the following:
• HCF Lift, Lift Motor
• HCF Feed Motor
Procedure
Enter Component Control [078-003 or 004 Tray 6 Feed/Lift Motor ON]. The Tray 6 Feed/Lift
Motor (PL 18.4) can be heard (the lifted paper plate drops when the tray is opened).
YN
Check the connections of JF57 and JF06. JF57 and JF06 are connected correctly.
YN
Connect JF57 and JF06.
Check the wire-wound resistance of Tray 6 Takeaway Motor is approx. 0.8 ohms at the mea-
surement points below.
• JF57-3 to pins 1/2
• JF57-4 to pins 5/6
If OK, go to 8.9 BSD and troubleshoot the Tray 6 Takeaway Motor circuit.
Execute Component Control [078-101 Tray 6 Feed Out Sensor]. Move the actuator of the Tray
6 Feed Out Sensor.
The display changes.
YN
Go to 8.9 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Feed Out Sensor PF67-2 to HCF PWB PF01-2
• Tray 6 Feed Out Sensor PF67-1 to HCF PWB PF01-3
• Tray 6 Feed Out Sensor PF67-3 to HCF PWB PF01-1
If OK, replace the Tray 6 Feed Out Sensor (PL 18.7) then the HCF PWB (PL 18.8).
Check the HCF paper lift components and repair as required (PL 18.2, PL 18.3).
078-941 HCF Paper Tray Size Mismatch RAP
BSD-ON:7.15
HCF Paper Size Mismatch.
Initial Actions
Use recommended paper sizes
Procedure
Check connectors JF01, PF/JF51, PF/JF52, and PF/JF53 are connected correctly. The
connectors are connected correctly.
YN
Connect JF01, PF/JF51, PF/JF52, and PF/JF53.
Enter Component Control [078-202, Tray 6 Size Sensor (Letter)]. Actuate the sensor with a
piece of paper.
The display changes.
YN
Go to 7.15 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Size Sensor (Letter) Sensor JF51-2 to HCF PWB JF01-11
• Tray 6 Size Sensor (Letter) Sensor PF51-3 to HCF PWB JF01-12
• Tray 6 Size Sensor (Letter) Sensor PF51-1 to HCF PWB JF01-10
If OK, replace the Tray 6 Size Sensor (PL 18.8) then the HCF PWB (PL 18.8).
Component Control [078-203, Tray 6 Size Sensor (A3)]. Actuate the sensor with a piece of
paper.
The display changes.
YN
Go to 7.15 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Size Sensor (A3) Sensor JF52-2 to HCF PWB JF01-8
• Tray 6 Size Sensor (A3) Sensor JF52-3 to HCF PWB JF01-9
• Tray 6 Size Sensor (A3) Sensor JF52-1 to HCF PWB JF01-7
If OK, replace the Tray 6 Size Sensor (PL 18.8) then the HCF PWB (PL 18.8).
Component Control [078-204, Tray 6 In Sensor]. Actuate the sensor with a piece of paper.
The display changes.
YN
Go to 7.15 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Size Sensor (A3) Sensor JF53-2 to HCF PWB JF01-5
• Tray 6 Size Sensor (A3) Sensor JF53-3 to HCF PWB JF01-6
• Tray 6 Size Sensor (A3) Sensor JF53-1 to HCF PWB JF01-4
If OK, replace the Tray 6 In Sensor (PL 18.1) then the HCF PWB (PL 18.8).
Ensure the paper guilds are adjusted correctly to the paper size.
