February, 2008
2-367
WorkCentre 5225, 5230
024-985 , 024-989
Status Indicator Raps
Launch Version
024-985 MPT Feed Failure RAP
The job was aborted during MPT feed.
Initial Actions
• Refer to BSD 7.13.
• Check the operation of the MPT Guide.
Procedure
Check the document size. The size of the document is within the specification.
YN
Use a paper size within the specification.
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Check the installation and operation of the MPT Guide. The MPT Guide is installed correctly
and the actuator works.
YN
Reinstall the MPT Guide
Measure the voltage between the MCU PWB P411-3 (+) and GND (-) (BSD 7.13 Flag 1).
Manually operate the MPT Guide. As the MPT Guide moves, the voltage changes accord-
ingly.
YN
Check the connections of P/J107, P/J609, P/J605 and P/J411. P/J107, P/J609, P/
J605 and P/J411 are connected correctly.
YN
Connect P/J107, P/J609, P/J605 and P/J411.
Check the wire between J107 and J411 for an open circuit or a short circuit (BSD 7.13
Flag 1/Flag 2).
The wire between J107 and J411 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P411-1 (+) and GND (-) (BSD 7.13 Flag 2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Replace the MPT Paper Size Sensor (PL 7.3).
Replace the MCU PWB (PL 9.1).
024-989 Booklet Low Staple
Booklet Maker Stapler Low Staple signal is detected to be on at Staple operations.
Initial Actions
Check staples, set properly or add more staples.
Procedure
If failure continues check the proper operation of the Front or Rear Low Staple Switch. (BSD
12.26, BSD 12.27)
To Next Page
