February, 2008
2-568
WorkCentre 5225, 5230
091-910, 091-911
Launch Version
Status Indicator Raps
091-910 Waste Toner Bottle Position RAP
BSD-ON:9.9
The Waste Toner Bottle is not in the correct position.
Procedure
Check the installation of the Waste Toner Bottle. Waste Toner Bottle installation is correct.
YN
Correct the installation problem by checking for damaged mounting points.
Verify the condition of the circuit, BSD9.9, between the Waste Toner Position Sensor and MCU
PWB.
The circuit is free of damage.
YN
Repair the circuit as required.
Ensure the Waste Toner Bottle is installed correctly. Then check Waste Toner Bottle sensor operat-
ing voltage and output. The signal level voltage indicates the Waste Toner Bottle is cor-
rectly installed.
YN
There is a problem with the sensor. Repair or replace the Waste Toner Position Sensor
(PL 4.2).
Replace the MCU PWB (PL 9.1).
091-911 Waste Toner Full RAP
BSD-ON:9.9
The Waste Toner Bottle is full.
Procedure
Check the contents level of the Waste Toner Bottle. The Waste Toner Bottle is full.
YN
Verify the condition of the circuit, BSD9.9, between the Waste Toner Bottle Sensor and MCU
PWB.
The circuit is free of damage.
YN
Repair the circuit as required.
Ensure the Waste Toner Bottle is installed correctly. Then check Waste Toner Bottle Full Sen-
sor operating voltage and output. The signal level voltage indicates the Waste Toner
Bottle is full.
YN
Replace the MCU PWB (PL 9.1).
There is a problem with the sensor. Repair or replace the Waste Toner Full Sensor (PL
4.2).
Replace the Waste Toner Bottle. If the problem persists, return to the beginning of the RAP.
