February, 2008
2-337
WorkCentre 5225, 5230
024-747, 024-748
Status Indicator Raps
Launch Version
024-747 Print Instruction Failure RAP
The specified print parameter is abnormal.
Procedure
The center tray will not receive output, and output goes to Finisher.
YN
Call for next level of support.
Key operator is available to change settings.
YN
NOTE: Service procedure to restore output capability to center tray on Top Cover (PL
10.1).
1. Access Diagnostic Routines.
a. Enter UI Diagnostics (UI Diagnostic Mode).
b. Access Diagnostic Routines (UI Diagnostic Mode).
2. Select NVM Read/Write.
3. Enter Chain-Link 742-100
4. Select Confirm.
NOTE: Display now shows Current Value (Zero)
5. To enter new value (one), press 1 on the numeric keypad, then Select Save
NOTE: The Current Value now reads 1.
6. Select Close.
7. Select Close again. Power off and on if the setting is not active.
NOTE: Customer procedure to restore output capability to center tray on Top Cover (PL 10.1).
1. Press the Log In / Out Button on the Control Panel and enter 11111 using the number
keypad and select Confirm.
2. Select System Settings.
3. Select System Settings again.
4. Select Common Settings.
5. Select Other Settings.
6. Select Extended Tray Module and select Change Setting.
7. Select Offset Stacking Module.
8. Select Save.
9. Select Close.
10. Select Close again.
11. Select Close again.
12. Select Exit. Power off and on if the setting is not active.
024-748 Bates Numbering Digit Over RAP
Bates Numbering Digit Over.
Procedure
Reduce the number of document pages so that the user-specified number of digits are not
exceeded, or increase number of digits specified by user; retry coping.
