February, 2008
2-579
WorkCentre 5225, 5230
094-417, 094-420
Status Indicator Raps
Launch Version
094-417 BTR Unit Pre Warning RAP
The BTR is near end of life.
Procedure
Verify that the BTR is near end of life (Detailed Maintenance Activities). The BTR is near end
of life.
YN
Replace the MCU PWB (PL 9.1).
There is no need for service at this time. Return to Service Call Procedures.
094-420 BTR Unit Warning RAP
The BTR reached end of life.
Procedure
Verify that the BTR Assembly is at end of life (Detailed Maintenance Activities). The BTR
Assembly is at end of life.
YN
Replace the MCU PWB (PL 9.1).
Replace the BTR Assembly (PL 2.6).
