WorkCentre 5225, 5230
Change Tag Introduction, IOT/Processor (P) Tags
General Procedures
Launch Version
Change Tag Introduction
Important modifications to the copier are identified by a tag number which is recorded on a tag
matrix. The tag matrix for the IOT (Processor) is molded into the inside of the Front Door.
This section describes all of the tags associated with the copier, as well as multinational appli-
cability, classification codes, and permanent or temporary modification information.
Classification Codes
A tag number may be required to identify differences between parts that cannot be inter-
changed, or differences in diagnostic, repair, installation, or adjustment procedures.
A tag number may also be required to identify the presence of optional hardware, special non-
volatile memory programming, or whether mandatory modifications have been installed. Each
tag number is given a classification code to identify the type of change that the tag has made.
The classification codes and their descriptions are listed in the table below.
IOT/Processor (P) Tags
IOT/Processor TAGs are shown below.
TAG: P-00X
CLASS: M
CUT IN DATE: xx/xx/xxx
NAME: Tag 1
KIT NUMBER: 701PXXXXX
NOTE: Announced in Service Bulletin TXXXX-XX-XX. Foreign Interface Option also enabled.
Table 1 Code Description
Classification Code Description
M Mandatory tag
N Tag not installed in the field
O Optional tag
R Repair tag
