Xerox WorkCentre 5230 User Manual

February, 2008
2-604
WorkCentre 5225, 5230
116-352, 116-353
Launch Version
Status Indicator Raps
116-352 NetWare Software RAP
An internal shutdown occurred after a NetWare processing error.
Initial Actions
Power Off/On
Procedure
Pull out and insert or replace the DIMM (PL 9.2).
If the problem persists reload Software (ADJ 9.3.1).
If the problem persists, replace the ESS PWB (PL 9.2).
116-353 HDD Mechanical RAP
A mechanical error occurred in the HDD.
Initial Actions
Power Off/On
Procedure
Check the connection of each ESS PWB connector. The connectors are correctly connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Check the HDD electrical connections (PL 9.2).
If the problem persists perform Hard Disk Diagnostic Program.
If the problem persists replace the HDD (PL 9.2).

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
