2-139
WorkCentre 5225, 5230
012-283
Status Indicator Raps
Launch Version
012-283 Set Clamp Home Sensor On Failure RAP
BSD-ON:12.23
After the Set Clamp started operation, the Set Clamp Home Sensor did not turn On within
200ms.
Initial Actions
• Power OFF/ON
• Remove foreign substances in the Eject Clamp mechanism.
Procedure
Manually operate the Eject mechanism. The Eject mechanism moves smoothly.
YN
Replace the parts that are interfering with operation.
Execute Component Control[012-251 Set Clamp Home Sensor]. Actuate the Eject Clamp
Home Sensor with paper. The display changes.
YN
Check the connections of J8871 and P/J8988. J8871 and P/J8988 are connected
correctly.
YN
Connect J8871 and P/J8988.
Check the wire between J8871 and J8988 for an open circuit or a short circuit (BSD
12.22).
The wire between J8871 and J8988 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8988-12 (+) and GND (-) (BSD 12.22).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8988-11 (+) and GND (-) (BSD 12.22).
Actuate the Eject Clamp Home Sensor with paper. The voltage changes.
YN
Replace the Eject Clamp Home Sensor (PL 23.11).
Replace the Finisher PWB (PL 23.16).
Alternately execute Component Control[012-054 Eject Motor FWD LO] and Component Con-
trol[012-055 Eject Motor FWD HI]. The Eject Motor (PL 22.9) starts up.
YN
Check the connections of P/J8878 and P/J8983. P/J8878 and P/J8983 are con-
nected correctly.
YN
Connect P/J8878 and P/J8983.
Check the wire between J8878 and J8983 for an open circuit or a short circuit (BSD
12.22).
The wire between J8878 and J8983 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Eject Motor (PL 22.9) between each point of J8878-1/3/4/6
(BSD 12.22).
The resistance is approx. 2Ohm.
YN
Replace the Eject Motor (PL 22.9).
Measure the voltage between the Finisher PWB (PL 23.16) P8983-5/6/7/8 (+) and GND (-
) (BSD 12.22).
The voltage is approx. +24VDC.
YN
Replace the Finisher PWB (PL 23.16).
Replace the Eject Motor (PL 22.9). If the problem persists, replace the Finisher PWB (PL
23.16).
Replace the Finisher PWB (PL 23.16).
A
A
B
B
