February, 2008
2-314
WorkCentre 5225, 5230
024-928 (A-Finisher), 024-930 (A-Finisher)
Launch Version
Status Indicator Raps
024-928 (A-Finisher) Scratch Sheet Compile
BSD-ON:12.2
Sheet Information command made abnormal paper (scratched paper) reported by the IOT
ejected into the compiler.
NOTE: This Fail Code is an operation message. If this fail code is frequently declared, perform
the procedure below.
Initial Actions
• Check that the Top Cover can be opened and closed.
• Power Off/On.
Procedure
Check the specifications of paper. The paper is in spec.
YN
Replace the paper with new paper that is in spec.
Check the condition of the paper. The paper is in normal condition without any problem
that causes the paper to be bent or caught.
YN
Resolve any problem that causes the paper to be bent or caught.
Check for a Fail Code. Another Fail Code is displayed.
YN
If the problem continues, replace the Finisher PWB (PL 22.7).
Go to the appropriate Fault Code.
024-930 (A-Finisher) Stacker Tray Full Stack
BSD-ON:12.8
One of the following:
• At Power On, the Stack Height Sensor detected the height and the Full position.
• During the operation of adjusting (lowering) the height of the Stacker Tray for small paper
to be ejected, the Full position was detected.
• During the operation of adjusting (lowering) the height of the Stacker Tray for large paper
to be ejected, the Half position (Full-of-Large-Sheets position) was detected.
• With the Half position (Full-of-Large-Sheets position) already detected, paper (large
paper) a stack of which is limited to the Half position was ejected.
Initial Actions
• Check that the Stack Height Sensor is properly installed, not broken and has no foreign
objects.
• Check Stacker Stack Sensors 1 and 2 are properly installed and free from foreign objects
and that their actuators are not broken.
• Power Off/On.
Procedure
Check for remaining paper and foreign objects on the Stacker Tray. The Stacker Tray is free
of paper or foreign objects.
YN
Remove the remaining paper and/or foreign object(s).
Check the drive mechanism to the Stacker Tray for a deformed or broken part and not-seated
gears.
The drive mechanism is in normal condition, not deformed or broken and with no
not-seated gears.
YN
Repair the Stacker Tray mechanism.
Enter Component Control [012-267]. Block and unblock the Stack Height Sensor with a piece
of paper.
The display changes.
YN
Check the connections of P/J8708 and P/J8727. P/J8708 and P/J8727 are securely
connected.
YN
Connect P/J8708 and P/J8727 securely.
Check for an open or short circuit between J8708 and J8727. The wires between
J8708 and J8727 are OK.
YN
Repair the open or short circuit.
Measure the voltage between J8708-3 (+) on the Finisher PWB and GND (-). The volt-
age is approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
A B
