Measure the resistance of the Carriage Motor (PL 11.5). The resistance between J721-
1/2 and J721-3/4/5/6 is approx. 1Ohm.
YN
Replace the Carriage Motor (PL 11.5).
Measure the voltage between the IIT/IPS PWB (PL 11.3) P721-1/2 (+) and GND (-)(BSD
6.3 Flag 1).
The voltage is approx. +24VDC.
YN
Replace the IIT/IPS PWB (PL 11.3).
Replace the Carriage Motor (PL 11.5)
If the problem persists, replace the IIT/IPS PWB (PL 11.3).
Replace the IIT/IPS PWB (PL 11.3).
062-371 Lamp Illumination RAP
BSD-ON: 6.3/6.2
The amount of light from Exposure Lamp is inadequate which gets incident on CCD at the start of
scan or at the initialization of IIT after power on.
Procedure
Check the lamp, lens, mirror and the white correcting plate for abnormalities such as contamination
and deterioration.
Abnormality such as contamination or deterioration of the lamp, lens,
mirror or the white correcting plate is found.
YN
Replace the lamp, lens, mirror or the white correcting plate.
Execute Component Control [062-002 IIT Exposure Lamp]. The Exposure Lamp lights up.
YN
Check the connections of P/J703, P/J702 and P/J7231. P/J703, P/J702 and P/J7231
are connected correctly.
YN
Connect P/J703, P/J702 and P/J7231.
Check the wire between J702 and J7231 for an open circuit or a short circuit. The wire
between J702 and J7231 is conducting without an open circuit or a short circuit.
YN
Replace the Lamp Wire Harness (PL 11.6).
Measure the voltage between the IIT/IPS PWB (PL 13.3) P7231-1 (+) and GND (-), and
between P7231-2 (+) and GND (-) (BSD 6.3 Flag 4).
The voltage is approx. +24VDC.
YN
Replace the IIT/IPS PWB (PL 11.3).
Replace the Exposure Lamp (PL 11.6)
If the problem persists, replace the Lamp Ballast PWB (PL 11.6)
If the problem persists, replace the IIT/IPS PWB (PL 13.3).
Check the connections of P/J700 and P/J7101. P/J700 and P/J7101 are connected cor-
rectly.
YN
Connect P/J700 and P/J7101.
Replace the Lens Kit Assembly (PL 11.4)
If the problem persists, replace the IIT/IPS PWB (PL 11.3).
A B

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
