Xerox WorkCentre 5230 User Manual

February, 2008
2-283
WorkCentre 5225, 5230
018-707, 018-708
Status Indicator Raps
Launch Version
018-707 LDAP RAP
There is an error in the Lightweight Directory Access Protocol.
Procedure
Verify that print jobs are printing or print a Configuration Report and verify that network setup set-
tings are indicated. The printer is operational or the Config Report indicates valid network
settings.
YN
Check for damage with the network connection. If there is no damage then there is a problem
with the network. Tell the customer that the network requires service.
There is a problem with the LDAP setups on the machine or with the remote LDAP server. Ask the
customer to verify the machine LDAP setups. If OK then there is a problem with the remote LDAP
server.
018-708 LDAP RAP
There is an error in the Lightweight Directory Access Protocol.
Procedure
Verify that print jobs are printing or print a Configuration Report and verify that network setup set-
tings are indicated. The printer is operational or the Config Report indicates valid network
settings.
YN
Check for damage with the network connection. If there is no damage then there is a problem
with the network. Tell the customer that the network requires service.
There is a problem with the LDAP setups on the machine or with the remote LDAP server. Ask the
customer to verify the machine LDAP setups. If OK then there is a problem with the remote LDAP
server.

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
