February, 2008
2-354
WorkCentre 5225, 5230
024-953, 024-954
Launch Version
Status Indicator Raps
024-953 Tray 4 Empty RAP
Tray 4 has run out of paper.
Initial Actions
• Refer to BSD 7.10/7.12.
Procedure
Check the installation of the Tray 4 No Paper Sensor (PL 12.3/PL 13.6) and the operation of
the actuator.
The Tray 4 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 4 Level Sensor.
Execute Component Control[071-204 Tray 4 No Paper Sensor]. Manually activate the Tray 4
No Paper Sensor (PL 12.3/PL 13.6).
The display changes.
YN
Check the connections of P/J102A, P/J661A and P/J549. P/J102A, P/J661A and P/
J549 are connected correctly.
YN
Connect P/J102A, P/J661A and P/J549.
Check the wire between J102A and J549 for an open circuit or a short circuit (BSD 7.10
Flag 4/Flag 5 / BSD 7.12 Flag 4/Flag 5).
The wire between J102A and J549 is con-
ducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Tray Module PWB P549-A10 (+) and GND (-) (BSD
7.10 Flag 5 / BSD 7.12 Flag 5).
The voltage is approx. +5VDC.
YN
Replace the Tray Module PWB (PL 12.6/PL 13.8).
Measure the voltage between the Tray Module PWB P549-A12 (+) and GND (-) (BSD
7.10 Flag 4 / BSD 7.12 Flag 4).
Activate the actuator of the Tray 4 No Paper Sensor (PL 12.3/PL 13.6). The voltage
changes.
YN
Replace the Tray 4 No Paper Sensor (PL 12.3/PL 13.6).
Replace the Tray Module PWB (PL 12.6/PL 13.8).
Replace the Tray Module PWB (PL 12.6/PL 13.8).
024-954 MPT Empty RAP
The MPT has run out of paper.
Initial Actions
• Refer to BSD 7.13.
Procedure
Check the installation of the MPT No Paper Sensor (PL 7.1) and the operation of the actuator.
The MPT No Paper Sensor is installed correctly and the actuator works.
YN
Reinstall the MPT No Paper Sensor.
Execute Component Control[071-205 MPT No Paper Sensor]. Manually activate the MPT No
Paper Sensor (PL 7.1).
The display changes.
YN
Check the connections of P/J108, P/J605 and P/J411. P/J108, P/J605 and P/J411
are connected correctly.
YN
Connect P/J108, P/J605 and P/J411.
Check the wire between J108 and J411 for an open circuit or a short circuit (BSD 7.13
Flag 3/Flag 4).
The wire between J108 and J411 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P411-6 (+) and GND (-) (BSD 7.13 Flag 4).
The voltage is approximately. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P411-8 (+) and GND (-) (BSD 7.13 Flag 3).
Activate the actuator of the MPT No Paper Sensor (PL 7.1). The voltage changes.
YN
Replace the MPT No Paper Sensor (PL 7.1).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
