WorkCentre 5225, 5230
024-966, 024-967
Status Indicator Raps
Launch Version
024-966 ATS/APS No Destination Error RAP
APS/ATS is unable to detect the paper size.
Initial Actions
• Refer to BSD 7.1- 7.6.
• Reload the tray.
Procedure
Check the installation of the relevant Size Sensor. The relevant Size Sensor is installed cor-
rectly.
YN
Install the relevant Size Sensor correctly.
Go to the BSD 7.1 -7.6 Tray 1 -4 Paper Size Sensing and check the connectors.
024-967 Different width Mix Paper detect (Stapler job) RAP
Paper Width Mix was detected during stapling.
Initial Actions
• Refer to BSD 3.4.
Procedure
Check the connection of each MCU PWB connector. The connectors are connected cor-
rectly.
YN
Connect the connectors.
Check the connection of each Finisher PWB connector. The connectors are connected cor-
rectly.
YN
Connect the connectors.
Check the wire between P/J416 and J8843 for an open circuit or a short circuit (BSD 3.4).
The wire between P/J416 and J8843 is conducting without an open circuit or a short cir-
cuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P/J416-A3 (+) and GND (-) (BSD 3.4). The
voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Replace the Finisher PWB (PL 22.7). If the problem persists, replace the MCU PWB (PL 9.1).
