WorkCentre 5225, 5230
071-105
Status Indicator Raps
Launch Version
071-105 Tray 1 Registration Sensor On JAM RAP
BSD-ON:8.7
After the Tray 1 Feed/Lift Motor turned On, the Registration Sensor did not turn On within the
specified time.
Initial Actions
• If jams occur after servicing components in the Left Upper Cover Assembly (PL 2.8), the
Chute Assembly may be out of position (PL 2.8). Verify installation.
• Power OFF/ON
Procedure
Check the Transport Roll for wear and paper powder. The Transport Roll is ok.
YN
Replace the Transport Roll.
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Execute Component Control[089-100 Registration Sensor]. Manually activate the actuator of
the Registration Sensor (PL 2.4).
The display changes.
YN
Check the connection of P/J104. P/J104 is connected correctly.
YN
Connect P/J104.
Check the wire between J104 and J403 for an open circuit or a short circuit (BSD 8.7).
The wire between J104 and J403 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P403B-13 (+) and GND (-) (BSD 8.7 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P403B-8 (+) and GND (-) (BSD 8.7 Flag 1).
Actuate the Registration Sensor with paper. The voltage changes.
YN
Replace the Registration Sensor (PL 2.4).
Replace the MCU PWB (PL 9.1).
Execute Component Control[071-007 Tray 1 Feed/Lift Motor ON]. The Tray 1 Feed/Lift Motor
(PL 2.3) can be heard.
YN
Check the connections of P/J201, P/J601 and P/J409. P/J201, P/J601 and P/J409
are connected correctly.
YN
Connect P/J201, P/J601 and P/J409.
Remove the Tray 1 Feed/Lift Motor (PL 2.3) and the Tray 2 Feed/Lift Motor (PL 2.3).
Replace the Tray 1 Feed/Lift Motor with the Tray 2 Feed/Lift Motor.
Execute Component Control[071-007 Tray 1 Feed/Lift Motor ON]. The Tray 2 Feed/Lift
Motor (PL 2.3) can be heard.
YN
Return the Tray 2 Feed/Lift Motor to its original position.
Check the wire between J201 and J409 for an open circuit or a short circuit (BSD 7.7
Flag 1).
The wire between J201 and J409 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the MCU PWB (PL 9.1).
Return the Tray 2 Feed/Lift Motor to its original position.
Replace the Tray 1 Feed/Lift Motor (PL 2.3).
Replace the MCU PWB (PL 9.1).
