Xerox WorkCentre 5230 User Manual

February, 2008
2-136
WorkCentre 5225, 5230
012-263, 012-265
Launch Version
Status Indicator Raps
Check the wire between J8883 and J8984 for an open circuit or a short circuit (BSD
12.18).
The wire between J8883 and J8984 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Front Tamper Motor between J8984-19 and each point of
J8984-1/3/4/6 (BSD 12.18).
The resistance is approx. 750Ohm.
YN
Replace the Front Tamper Motor (PL 23.12).
Measure the voltage between the Finisher PWB J8984-19 and each point of J8984-1/3/4/
6 (BSD 12.18).
The voltage is approx. +24VDC.
YN
Replace the Finisher PWB (PL 23.16).
Replace the Front Tamper Motor (PL 23.12). If the problem persists, replace the Finisher
PWB (PL 23.16).
Replace the Finisher PWB (PL 23.16).
012-265 Booklet Folder Home Sensor OFF Fail
When the Booklet Home moves from Home position, the Folder Home Sensor did not turn OFF
within the specified time.
Initial Actions
• The Folder Home Sensor for improper installation
• The Folder Home Sensor connectors for connection failure
• The Booklet Fold Knife Motor connectors for connection failure
• The Knife drive mechanism for a foreign substance
Procedure
Manually move the Booklet Tamper to both ends. Enter Component Control [013-022, Folder
Knife Motor FWD] and [013-023, Folder Knife Motor REV] alternately. Select Start.
The
Booklet Folder Roll Motor energizes.
YN
Select Stop. Check continuity between the Booklet Folder Knife Motor and the Booklet
PWB and between the Booklet PWB and the Finisher PWB.
The continuity check is
OK.
YN
Repair the open circuit or short circuit.
Replace the Booklet Folder Knife Motor (PL 23.15). If the problem continues, replace the
Booklet PWB (PL 23.21). If the problem persists, replace Finisher PWB (PL 23.16).
Select Stop. Select [13-101, Folder Home Sensor]. Select Start. Block/unblock the Folder
Home Sensor. The display changed.
YN
Select Stop. Check continuity between the Folder Home Sensor and the Booklet PWB
and between the Booklet PWB and the Finisher PWB.
The continuity check is OK.
YN
Repair the open circuit or short circuit.
Replace the Folder Home Sensor (PL 23.15). If the problem continues, replace the Book-
let PWB (PL 23.21). If the problem persists, replace Finisher PWB (PL 23.16).
Select Stop. If the problem continues, replace the Finisher PWB (PL 23.16).
A B
