Status Indicator Raps
024-949 Tray 4 Out Of Place RAP
The Tray 4 Paper Size Switch detected no tray.
Initial Actions
• Refer to BSD 7.4/7.6.
• Reload the tray correctly.
• Check the operation of the tray actuator.
Procedure
[For 2TM]
Remove Trays 3 and 4. Replace Tray 3 with Tray 4. [024-949] occurs.
YN
Replace the faulty part of the Tray 4 Actuator.
Check the installation of the Tray 4 Paper Size Switch. The Tray 4 Paper Size Switch is
installed correctly.
YN
Install the Tray 4 Paper Size Switch correctly.
Go to the BSD 7.4 Tray 4 Paper Size Sensing and check the connectors.
[For TTM]
Check the Tray 4 Actuator. The Tray 4 Actuator is not distorted.
YN
Replace the faulty part of the Tray 4 Actuator.
Check the installation of the Tray 4 Paper Size Switch. The Tray 4 Paper Size Switch is
installed correctly.
YN
Install the Tray 4 Paper Size Switch correctly.
Go to the BSD 7.6 Tray 4 Paper Size Sensing and check the connectors.
024-950 Tray 1 Empty RAP
Tray 1 has run out of paper.
Initial Actions
• Refer to BSD 7.7.
Procedure
Check the installation of the Tray 1 No Paper Sensor (PL 2.3) and the operation of the actua-
tor. The Tray 1 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 1 Level Sensor.
Execute Component Control[071-201 Tray 1 No Paper Sensor]. Manually activate the Tray 1
No Paper Sensor (PL 2.3).
The display changes.
YN
Check the connections of P/J101, P/J601 and P/J409. P/J101, P/J601 and P/J409
are connected correctly.
YN
Connect P/J101, P/J601 and P/J409.
Check the wire between J101 and J409 for an open circuit or a short circuit (BSD 7.7 Flag
4/Flag 5).
The wire between J101 and J409 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P409A-10 (+) and GND (-) (BSD 7.7 Flag
5).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P409B-12 (+) and GND (-) (BSD 7.7 Flag
4).
Activate the actuator of the Tray 1 No Paper Sensor (PL 2.3). The voltage changes.
YN
Replace the Tray 1 No Paper Sensor (PL 2.3).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
