Status Indicator Raps
005-916 CVT APS No2 Sensor Static JAM RAP
Paper remains on the APS Sensor 2.
Initial Actions
• Refer to BSD 5.4.
• Remove the paper.
Procedure
Execute Component Control[005-219 DADF APS 2 Sensor]]. Actuate the DADF APS 2 Sensor
with paper.
The display changes.
YN
Check the connections of P/J778 and P/J761. P/J778 and P/J761 are connected cor-
rectly.
YN
Connect P/J778 and P/J761.
Check the wire between J778 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
9/Flag 10).
The wire between J778 and J761 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-1 (+) and GND (-) (BSD 5.4 Flag
10).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P761-3 (+) and GND (-) (BSD 5.4 Flag 9).
Actuate the DADF APS 2 Sensor with paper. The voltage changes.
YN
Replace the DADF APS 2 Sensor (PL 15.7).
Replace the DADF PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
