Xerox WorkCentre 5230 User Manual

February, 2008
2-556
WorkCentre 5225, 5230
077-310, 077-329
Launch Version
Status Indicator Raps
077-310 Controller Failed to send image RAP
BSD-ON:3.1
The MCU PWB did not receive the ESS PWB image-ready signal within the specified time.
Initial Actions
• Power OFF/ON
Procedure
Check the ROM version by executing NVM[740-007 ROM Version]. The ROM is the latest
version.
YN
Replace the ROM with the latest version.
Replace the MCU PWB (PL 9.1). If the problem persists, replace the ESS PWB (PL 9.2).
077-329 Main Motor Stop Error RAP
BSD-ON:3.1
Due to MCU PWB control failure, the Main Motor does not stop when no paper is being fed.
Initial Actions
• power OFF/ON
Procedure
Check the ROM version by executing NVM [740-007 ROM Version]. The ROM is the latest
version.
YN
Replace the ROM with the latest version.
Replace the MCU PWB (PL 9.1).

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
