February, 2008
2-676
WorkCentre 5225, 5230
124-333, 124-334
Launch Version
Status Indicator Raps
124-333 ASIC RAP
BSD-ON:16.1
A decompression error occurred in an ESS ASIC (Application Specific Integrated Circuit).
Initial Actions
Power Off/On
Procedure
Pull out and insert the DIMM (PL 9.2) Switch on the power. The problem persists.
YN
Return to Service Call Procedures.
Check the connection of each ESS PWB connector. The connectors are securely connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the ESS PWB (PL 9.2)
If the problem persists replace the DDR DIMM (PL 9.2).
124-334 Standard Font ROM RAP
BSD-ON:16.1
An error was detected in the standard Built-In Font ROM.
Procedure
Replace the PS DIMM (PL 9.2)
