February, 2008
2-80
WorkCentre 5225, 5230
005-906
Launch Version
Status Indicator Raps
005-906 CVT Feed Sensor Static JAM RAP
Paper remains on the DADF Feed Out Sensor.
Initial Actions
• Refer to BSD 5.4.
• Remove the paper.
Procedure
Execute Component Control[005-205 DADF Feed Out Sensor]. Actuate the DADF Feed Out
Sensor (PL 15.9) with paper.
The display changes.
YN
Check the connections of P/J769 and P/J758. P/J769 and P/J758 are connected cor-
rectly.
YN
Connect P/J769 and P/J758.
Check the wire between J769 and J758 for an open circuit or a short circuit (BSD 5.4 Flag
13/Flag 14).
The wire between J769 and J758 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P758-1 (+) and GND (-) (BSD 5.4 Flag
14).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P758-3 (+) and GND (-) (BSD 5.4 Flag 13).
Actuate the DADF Feed Out Sensor with paper. The voltage changes.
YN
Replace the DADF Feed Out Sensor (PL 15.9).
Replace the DADF PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
