February, 2008
2-511
WorkCentre 5225, 5230
062-211, 062-277
Status Indicator Raps
Launch Version
062-211 IIT/IPS PWB EEPROM RAP
BSD-ON: 3.1
The IPS EEPROM failed during the Read/Write operation.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Switch on the power. The problem persists.
YN
Return to Service Call Procedures
Replace the IIT/IPS PWB (PL 11.3).
062-277 IIT/IPS PWB DADF PWB Communication RAP
BSD-ON: 3.5
Transmission error occurred between the IIT/IPS PWB and the DADF PWB.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Check the connection of each DADF PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Check the wire between P/J751 and P750, and between P/J752 and P750 for an open cir-
cuit or a short circuit (BSD 3.5 Flag 1). The wires between P/J751 and P750, and between
P/J752 and P750 are conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the IIT/IPS PWB (PL 11.3).
If the problem persists, replace the DADF PWB (PL 15.3).
