February, 2008
2-512
WorkCentre 5225, 5230
062-300, 062-310
Launch Version
Status Indicator Raps
062-300 Platen Interlock Open RAP
BSD-ON: 6.1
The Platen Interlock is open.
Procedure
Check opening/closing of the Platen Cover. The Platen Cover can be opened/closed.
YN
Reinstall the Platen Cover correctly.
Check the installation of the Platen Angle Sensor. The Platen Angle Sensor is installed cor-
rectly.
YN
Install the Platen Angle Sensor correctly.
Execute Component Control [062-301 Platen Angle Sensor]. Open and close the Platen
Cover. The display changes.
YN
Check the connections of P/J725 and P/J722. P/J725 and P/J722 are connected cor-
rectly.
YN
Connect P/J725 and P/J722.
Check the wire between J725 and J722 for an open circuit or a short circuit (BSD 6.1 Flag
5/Flag 6).
The wire between J725 and J722 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the IIT/IPS PWB P722-B7 (+) and GND (-) (BSD 6.1 Flag
6).
The voltage is approx. +5VDC.
YN
Replace the IIT/IPS PWB (PL 11.3).
Measure the voltage between the IIT/IPS PWB P722-B9 (+) and GND (-) (BSD 6.1 Flag
5).
Actuate the Platen Angle Sensor with paper. The voltage changes.
YN
Replace the Platen Angle Sensor (PL 11.4).
Replace the Platen Angle Sensor (PL 13.4).
Replace the IIT/IPS PWB (PL 11.3).
062-310 IIT/IPS PWB Controller Communication RAP
BSD-ON: 3.1
Transmission error occurred between the IIT/IPS PWB and the ESS PWB.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Check the connection of each ESS PWB connector. The connectors are securely connected.
YN
Connect the connectors.
Check the wire between P/J720, P/J7193 and P/J320 for an open circuit or a short circuit
(BSD 3.1 Flag 3/Flag 4).
The wire between J720, 719, and J320 is conducting without an
open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the IIT/IPS PWB (PL 11.3).
If the problem persists, replace the ESS PWB (PL 9.2).
