February, 2008
2-82
WorkCentre 5225, 5230
005-908, 005-909
Launch Version
Status Indicator Raps
005-908 CVT Registration Sensor Static JAM RAP
Paper remains on the DADF Registration Sensor.
Initial Actions
• Refer to BSD 5.4.
• Remove the paper.
Procedure
Execute Component Control[005-110 DADF Registration Sensor]. Actuate the DADF Registra-
tion Sensor (PL 15.7) with paper. The display changes.
YN
Check the connections of P/J782 and P/J761. P/J782 and P/J761 are connected cor-
rectly.
YN
Connect P/J782 and P/J761.
Check the wire between J782 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
1/Flag 2).
The wire between J782 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-15 (+) and GND (-) (BSD 5.4 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P761-14 (+) and GND (-) (BSD 5.4 Flag 1).
Actuate the DADF Registration Sensor with paper. The voltage changes.
YN
Replace the DADF Registration Sensor (PL 15.7).
Replace the DADF PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
005-909 DADF Lead Sensor Static Jam
Lead Reg Sensor On detected at the timing below:
1. Power On
2. Feeder Cover Interlock Close
3. Platen Interlock Close.
Procedure
If the problem occurs frequently, make sure that there is no obstacle blocking the light path on
Lead Reg Sensor. Check the connections between the Lead Reg Sensor and the DADF PWB.
If OK, replace the Lead Reg Sensor. If the problem persists, replace the DADF PWB (PL 15.3).
To Next Page
