Xerox WorkCentre 5230 User Manual

February, 2008
2-71
WorkCentre 5225, 5230
005-198
Status Indicator Raps
Launch Version
005-198 Too Short Size JAM RAP
The system detected a document with a length shorter than 115mm in the Slow Scan Direction.
Initial Actions
• Refer to BSD 5.4.
Procedure
Check the document size. The size of the document is within the specification.
YN
Use a paper size within the specification.
Execute Component Control[005-205]. Actuate the DADF Feed Out Sensor (PL 15.9) with
paper.
The display changes.
YN
Check the connections of P/J769 and P/J758. P/J769 and P/J758 are connected cor-
rectly.
YN
Connect P/J769 and P/J758.
Check the wire between J769 and J758 for an open circuit or a short circuit (BSD 5.4 Flag
13/Flag 14).
The wire between J769 and J758 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P758-1 (+) and GND (-) (BSD 5.4 Flag
14).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P758-3 (+) and GND (-) (BSD 5.4 Flag 13).
Actuate the DADF Feed Out Sensor with paper. The voltage changes.
YN
Replace the DADF Feed Out Sensor (PL 15.9).
Replace the DADF PWB (PL 15.3).
Execute Component Control[005-206]. Actuate the DADF Pre Registration Sensor (PL 15.7)
with paper.
The display changes.
YN
Check the connections of P/J781 and P/J761. P/J781 and P/J761 are connected cor-
rectly.
YN
Connect P/J781 and P/J761.
Check the wire between J781 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
3/Flag 4).
The wire between J781 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-10 (+) and GND (-) (BSD 5.4 Flag
4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P761-12 (+) and GND (-) (BSD 5.4 Flag 3).
Actuate the DADF Pre Registration Sensor with paper. The voltage changes.
YN
Replace the DADF Pre Registration Sensor (PL 15.7).
Replace the DADF PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
A
A
B
B
