February, 2008
2-569
WorkCentre 5225, 5230
091-912, 091-913
Status Indicator Raps
Launch Version
091-912 Xerographics Drum Module Installation RAP
BSD-ON:9.1/4.1
The Xerographics Drum is not installed.
Procedure
Check the installation of the Drum Cartridge (PL 4.1). The Drum Cartridge installation is
correct.
YN
Correct the installation (PL 4.1).
Verify the condition of the circuit between the Drum Cartridge Position Sensor and MCU PWB. The
circuit is free of damage.
YN
Repair the circuit as required.
Replace the MCU PWB (PL 9.1).
091-913 Drum Cartridge End of Life RAP
BSD-ON:9.1
It is time to replace the Drum Cartridge.
Initial Actions
• Power Off/On
• Reload the Xero Drum Cartridge.
Procedure
Check the Drum Cartridge for failure or foreign substances. There are no foreign substances
and nothing has failed.
YN
Repair the failure and remove the foreign substances.
Check the installation of the XERO CRUM PWB. The XERO CRUM PWB is installed correctly.
YN
Install the XERO CRUM PWB correctly (PL 4.2).
Check the connection of the MCU PWB P/J419. P/J419 is connected correctly.
YN
Connect P/J407.
Check the connection of the XERO CRUM PWB P/J126. P/J126 is connected correctly.
YN
Connect P/J142.
Check the wire between J419 and P1126 for an open circuit or a short circuit (BSD 9.1). The wire is
conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB J419-1 (+) and GND (-) (BSD 9.1). The voltage is
approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Replace the Drum Cartridge (PL 4.1) If the problem persists, replace the XERO CRUM PWB
(PL 4.1) If the problem persists, replace the MCU PWB (PL 9.1).
