Xerox WorkCentre 5230 User Manual

February, 2008
2-567
WorkCentre 5225, 5230
091-402, 091-441
Status Indicator Raps
Launch Version
091-402 Drum Life Over RAP
The Drum Cartridge must be replaced.
Procedure
Check the HSFI counter. The usage is correct for the life expectancy of the drum.
YN
There is no need for service at this time. Return to Service Call Procedures.
Replace the Drum Cartridge (PL 4.1).
091-441 Drum Life Near End of Life RAP
The Drum Cartridge must be replaced soon.
Procedure
Check the HSFI counter. The usage is correct for the life expectancy of the drum.
YN
There is no need for service at this time. Return to Service Call Procedures.
Replace the Drum Cartridge (PL 4.1).

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
