February, 2008
2-68
WorkCentre 5225, 5230
005-194
Launch Version
Status Indicator Raps
005-194 Size Mismatch Jam on Mix-size RAP
In Mixed Size Originals, it was detected that the Fast Scan Direction size was different from the
width of the document guide.
Initial Actions
Refer to BSD 5.1.
Check the document guide and repeat the operation.
Check the operation of the Tray Side Guide (Front).
Check the operation of the Tray Side Guide (Rear).
Ensure customer refers to User Guide headings Document Feeder, Mixed Size Originals, and
Margin Shift for correct operation.
Procedure
Execute Component Control[005-221]. Actuate the DADF Tray Size 1 Sensor with paper. The
display changes.
YN
Check the connections of P/J771 and P/J759. P/J771 and P/J759 are connected cor-
rectly.
YN
Connect P/J771 and P/J759.
Check the wire between J771 and J759 for an open circuit or a short circuit (BSD 5.1Flag
1/Flag 2).
The wire between J771 and J759 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P759-3 (+) and GND (-) (BSD 5.1 Flag 2).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P759-2 (+) and GND (-) (BSD 5.1 Flag 1).
Actuate the DADF Tray Size 1 Sensor with paper. The voltage changes.
YN
Replace the DADF Tray Size 1 Sensor (PL 15.10).
Replace the DADF PWB (PL 15.3).
Execute Component Control[005-222]. Actuate the DADF Tray Size 2 Sensor with paper. The
display changes.
YN
Check the connections of P/J772 and P/J759. P/J772 and P/J759 are connected cor-
rectly.
YN
Connect P/J772 and P/J759.
Check the wire between J772 and J759 for an open circuit or a short circuit (BSD 5.1 Flag
3/Flag 4).
The wire between J772 and J759 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P759-6 (+) and GND (-) (BSD 5.1 Flag 4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P759-5 (+) and GND (-) (BSD 5.1 Flag 3).
Actuate the DADF Tray Size 2 Sensor with paper. The voltage changes.
YN
Replace the DADF Tray Size 2 Sensor (PL 15.10).
Replace the DADF PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
A
A
B
B
