February, 2008
7-7
WorkCentre 5225, 5230
S/B Finisher Plug/Jack Locations
Wiring Data
Launch Version
S/B Finisher Plug/Jack Locations
How to use the Plug/Jack Location List
The Plug/Jack Location List below is provided to locate plugs, jacks, or other terminating
devices. Locate the desired termination device in the first column (Connector Number) of the
list. Refer to the second column (Figure Number) to determine the figure number of the electri
-
cal termination device. Refer to the (Item Number) column to determine the item number in the
adjacent Figure Number column. The fourth column supplies the title of the Figure.
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number
Figure Title
P/J590 Figure 3 15 SB Finisher Rear
P/J591 Figure 3 14 SB Finisher Rear
J8860 Figure 1 1 SB Finisher Horizontal Transport
J8861 Figure 1 4 SB Finisher Horizontal Transport
P/J8862 Figure 1 2 SB Finisher Horizontal Transport
P8863 Figure 1 7 SB Finisher Horizontal Transport
P8863 Figure 1 5 SB Finisher Horizontal Transport
J8864 Figure 1 8 SB Finisher Horizontal Transport
J8865 Figure 1 10 SB Finisher Horizontal Transport
J8866 Figure 1 6 SB Finisher Horizontal Transport
P/J8867 Figure 1 9 SB Finisher Horizontal Transport
J8868 Figure 4 4 SB Finisher Eject
J8869 Figure 4 3 SB Finisher Eject
J8870 Figure 3 24 SB Finisher Rear
J8871 Figure 3 23 SB Finisher Rear
J8872 Figure 3 21 SB Finisher Rear
J8873 Figure 3 2 SB Finisher Rear
J8874 Figure 3 1 SB Finisher Rear
J8875 Figure 3 22 SB Finisher Rear
P/J8876 Figure 4 5 SB Finisher Eject
P/J8877 Figure 3 20 SB Finisher Rear
P/J8878 Figure 3 7 SB Finisher Rear
P/J8879 Figure 3 5 SB Finisher Rear
J8880 Figure 4 7 SB Finisher Eject
J8881 Figure 4 11 SB Finisher Eject
J8882 Figure 4 6 SB Finisher Eject
P/J8883 Figure 4 8 SB Finisher Eject
P/J8884 Figure 4 10 SB Finisher Eject
J8885 Figure 2 7 SB Finisher Front
J8886 Figure 2 6 SB Finisher Front
J8887 Figure 2 5 SB Finisher Front
P/J8888 Figure 4 9 SB Finisher Eject
J8889 Figure 3 3 SB Finisher Rear
J8890 Figure 3 4 SB Finisher Rear
J8891 Figure 4 2 SB Finisher Eject
P/J8892 Figure 5 1 Booklet Maker Stapler Assembly
P/J8893 Figure 5 2 Booklet Maker Stapler Assembly
J8894 Figure 6 1 Booklet Maker PWB
P/J8895 Figure 6 3 Booklet Maker PWB
P/J8896 Figure 5 7 Booklet Maker Stapler Assembly
J8897 Figure 5 4 Booklet Maker Stapler Assembly
J8898 Figure 5 5 Booklet Maker Stapler Assembly
J8899 Figure 5 6 Booklet Maker Stapler Assembly
J8900 Figure 5 8 Booklet Maker Stapler Assembly
J8901 Figure 5 3 Booklet Maker Stapler Assembly
P/J8903 Figure 2 2 SB Finisher Front
P8903 Figure 4 1 SB Finisher Eject
J8904 Figure 2 3 SB Finisher Front
P/J8905 Figure 2 4 SB Finisher Front
P/J8906 Figure 6 2 Booklet Maker PWB
J8980 Figure 3 19 SB Finisher Rear
P/J8981 Figure 3 10 SB Finisher Rear
J8982 Figure 3 18 SB Finisher Rear
P/J8983 Figure 3 9 SB Finisher Rear
J8984 Figure 3 6 SB Finisher Rear
J8985 Figure 6 4 Booklet Maker PWB
P8985 Figure 3 17 SB Finisher Rear
P/J8986 Figure 3 8 SB Finisher Rear
J8987 Figure 1 3 SB Finisher Horizontal Transport
P8987 Figure 3 16 SB Finisher Rear
P/J8988 Figure 3 11 SB Finisher Rear
J8989 Figure 3 13 SB Finisher Rear
P/J8990 Figure 3 12 SB Finisher Rear
P/J8991 Figure 6 9 Booklet Maker PWB
P/J8992 Figure 6 7 Booklet Maker PWB
P/J8993 Figure 6 6 Booklet Maker PWB
P/J8994 Figure 6 5 Booklet Maker PWB
P/J8995 Figure 6 8 Booklet Maker PWB
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
