Xerox WorkCentre 5230 User Manual

February, 2008
2-151
WorkCentre 5225, 5230
012-923, 012-935
Status Indicator Raps
Launch Version
012-923 H-Transport Entrance SNR static JAM B RAP
BSD-ON:12.14
During standby, paper was detected by the H-Transport Entrance Sensor.
Initial Actions
Remove foreign substances on the sensor.
Power OFF/ON
Procedure
Execute Component Control[012-190 H-Transport Entrance Sensor]. Actuate the H-Transport
Entrance Sensor (PL 23.4) with paper.
The display changes.
YN
Check the connections of J8861 and J8987. J8861 and J8987 are connected cor-
rectly.
YN
Connect J8861 and J8987.
Check the wire between J8861 and J8987 for an open circuit or a short circuit (BSD
12.14).
The wire between J8861 and J8987 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8987-4 (+) and GND (-) (BSD 12.14).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8987-6 (+) and GND (-) (BSD 12.14).
Actuate the H-Transport Entrance Sensor with paper. The voltage changes.
YN
Replace the H-Transport Entrance Sensor (PL 23.4).
Replace the Finisher PWB (PL 23.16).
Replace the Finisher PWB (PL 23.16).
012-935 Paper at Xport Entrance Sensor
BSD-ON:12.16
Control logic reports paper at the Xport Entrance Sensor.
Initial Actions
• Check for obstructions in the paper path
• Check that the Finisher is dock correctly to ensure proper Transport Gate operation
Procedure
Enter Component Control [012-100], Finisher Entrance Sensor. Select Start. Actuate the Fin-
isher Entrance Sensor. The display changes.
YN
Check the connections of J8869 and P/J8988. J8869 and P/J8988 are connected
correctly.
YN
Connect J8869 and P/J8988.
Check the wire between J8861 and J8988 for an open circuit or a short circuit (BSD
12.14).
The wire between J8861 and J8988 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8988-6 (+) and GND (-) (BSD 12.16).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8988-5 (+) and GND (-) (BSD 12.16).
Actuate the Finisher Entrance Sensor with paper. The voltage changes.
YN
Replace the Finisher Entrance Sensor (PL 23.4).
Replace the Finisher PWB (PL 23.16).
Replace the Finisher PWB (PL 23.16).
