February, 2008
2-713
WorkCentre 5225, 5230
134-210, 134-211
Status Indicator Raps
Launch Version
134-210 Fax Controller Parameter RAP
BSD-ON:17.1
The parameter value is incorrect or the required parameter is not sent.
Initial Actions
Power Off/On
Procedure
Pull out and insert the FAX PWB (PL 9.3). The problem persists.
YN
Return to Service Call Procedures.
Check the electrical connections on the FAX PWB (PL 9.3). The connectors are securely
connected.
YN
Connect the connectors.
Switch on the power. The problem persists.
YN
Return to Service Call Procedures.
Replace the FAX PWB (PL 9.3).
134-211 FAX PWB RAP
BSD-ON:17.1
A failure is detected on the FAX PWB.
Initial Actions
Power Off/On
Procedure
Check the electrical connections on the FAX PWB (PL 9.3).
If the problem persists replace the FAX PWB (PL 9.3).

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
