Xerox WorkCentre 5230 User Manual

February, 2008
2-81
WorkCentre 5225, 5230
005-907
Status Indicator Raps
Launch Version
005-907 CVT Pre-Registration Sensor Static JAM RAP
Paper remains on the DADF Pre Registration Sensor.
Initial Actions
• Refer to BSD 5.4.
• Remove the paper.
Procedure
Execute Component Control[005-206 DADF Pre Registration Sensor]. Actuate the DADF Pre
Registration Sensor (PL 15.7) with paper.
The display changes.
YN
Check the connections of P/J781 and P/J761. P/J781 and P/J761 are connected cor-
rectly.
YN
Connect P/J781 and P/J761.
Check the wire between J781 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
3/Flag 4).
The wire between J781 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-10 (+) and GND (-) (BSD 5.4 Flag
4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P761-12 (+) and GND (-) (BSD 5.4 Flag 3).
Actuate the DADF Pre Registration Sensor with paper. The voltage changes.
YN
Replace the DADF Pre Registration Sensor (PL 15.7).
Replace the DADF PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
