Xerox WorkCentre 5230 User Manual

February, 2008
2-345
WorkCentre 5225, 5230
024-916, 024-917
Status Indicator Raps
Launch Version
YN
Repair the open circuit or short circuit.
Replace the Stacker Motor (PL 22.8). If the problem persists, replace the Finisher PWB
(PL 22.7).
Replace the Finisher PWB (PL 22.7). If the problem persists, replace the MCU PWB (PL 9.1).
024-917 Stacker Tray Staple Set Over Count RAP
The number of stapled copies exceeded the capacity of the Stacker Tray.
Initial Actions
• Refer to BSD 12.9.
Procedure
Check the connection of each Finisher PWB connector. The connectors are connected cor-
rectly.
YN
Connect the connectors.
Turn on the power again. [024-917] reoccurs.
YN
End
Replace the Finisher PWB (PL 22.7). If the problem persists, replace the MCU PWB (PL 9.1).
