Xerox WorkCentre 5230 User Manual

February, 2008
2-74
WorkCentre 5225, 5230
005-280, 005-284
Launch Version
Status Indicator Raps
005-280 DADF EPROM Failure RAP
The DADF-EEPROM failed during the Read/Write operation.
Initial Actions
• Refer to BSD 3.5.
Procedure
Check the connection of each DADF PWB connector. The connectors are connected cor-
rectly.
YN
Connect the connectors.
Turn on the power again. [005-280] reoccurs.
YN
Return to Service Call Procedures.
Replace the DADF PWB (PL 15.3).
005-284 DADF Auto Paper Selection Sensor Logic Failure
RAP
The combinations of outputs from the DADF APS 1 Sensor, DADF APS 2 Sensor and DADF
APS 3 Sensor are abnormal.
Initial Actions
• Refer to BSD 5.4.
Procedure
Execute Component Control[005-218]. Actuate the DADF APS 1 Sensor with paper. The dis-
play changes.
YN
Check the connections of P/J777 and P/J761. P/J777 and P/J761 are connected cor-
rectly.
YN
Connect P/J777 and P/J761.
Check the wire between J777 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
7/Flag 8).
The wire between J777 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-4 (+) and GND (-) (BSD 5.4 Flag 8).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P761-6 (+) and GND (-) (BSD 5.4 Flag 7).
Actuate the DADF APS 1 Sensor with paper. The voltage changes.
YN
Replace the DADF APS 1 Sensor (PL 15.7).
Replace the DADF PWB (PL 15.3).
Execute Component Control[005-219]. Actuate the DADF APS 2 Sensor with paper. The dis-
play changes.
YN
Check the connections of P/J778 and P/J761. P/J778 and P/J761 are connected cor-
rectly.
YN
Connect P/J778 and P/J761.
Check the wire between J778 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
9/Flag 10).
The wire between J778 and J761 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-1 (+) and GND (-) (BSD 5.4 Flag
10).
The voltage is approx. +5VDC.
A
