February, 2008
4-222
WorkCentre 5225, 5230
ADJ 7.1.2
Launch Version
Repairs and Adjustments
Adjustment
NOTE: To enter a negative number (a number less than 0) into NVM, press the Dial Pause
button on the Control Panel before entering the New Value.
1. Access Diagnostic Routines.
a. Enter UI Diagnostics (UI Diagnostic Mode).
2. Select NVM Read / Write, and enter Chain-Link for plain paper, side 1 (742-464).
3. Select Conform / Change.
4. Under Change Current Value enter the New Value. See the Table 1.
5. Select Save.
NOTE: When adjusting the inboard to outboard images from the HCF (Tray 6), negative num-
bers will move the image outboard and positive numbers will move the image inboard.
NOTE: In Table 1, all Descriptions are for Black and White and Color unless otherwise stated.
NOTE: The adjustment is 0.2mm per bit.
Table 1 HCF (Tray 6) NVM Settings for Side Edge Registration
Description NVM Default Values Range
Plain Paper Side 1 742-464 0 -25 to 25
Plain Paper Side 2 742-463 0 -25 to 25
Heavyweight 1 BW 742-465 0 -25 to 25
Heavyweight 1 Color 742-466 0 -25 to 25
Heavyweight 2 742-467 0 -25 to 25
Labels, BW 742-468 0 -25 to 25
Labels, Color 742-469 0 -25 to 25
Transparency 742-470 0 -25 to 25
