Xerox WorkCentre 5230 User Manual

February, 2008
2-517
WorkCentre 5225, 5230
062-389, 062-392
Status Indicator Raps
Launch Version
062-389 Carriage Over Run RAP
BSD-ON: 3.1
The carriage scanned beyond safe limits.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Switch on the power. The problem persists.
YN
Return to Service Call Procedures
Replace the IIT/IPS PWB (PL 11.3).
062-392 IIT/IPS PWB Memory Failure-1 RAP
BSD-ON: 3.1
• The IIT/IPS PWB RAM failed during the Read/Write operation.
• The Shading Memory failed during the Read/Write operation.
• The Gap Memory failed during the Read/Write operation.
• The ASIC (Application Specific Integrated Circuit) failed.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Switch on the power. The problem persists.
YN
Return to Service Call Procedures
Replace the IIT/IPS PWB (PL 11.3).

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
