Configuring and Viewing Device Port Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 108
D-Link UWS User Manual
Table 33: Port Configuration Fields
Field Description
Slot/Port Select the port from the menu to display or configure data for that port. If you
select All, the changes you make to the Port Configuration page apply to all
physical ports on the system.
Port Type For most ports this field is blank. Otherwise the possible values are:
• Mirrored: Indicates that the port has been configured as a monitoring port
and is the source port in a port mirroring session.
• Probe: Indicates that the port has been configured as a monitoring port
and is the destination port in a port mirroring session.
• Port Channel: Indicates that the port has been configured as a member of
a port-channel, which is also known as a link Aggregation Group (LAG).
For more information about port monitoring and probe ports, see “Multiple
Port Mirroring” on page 90. For information about configuring port channels,
see “Creating Port Channels (Trunking)” on page 209.
Mode Shows the Spanning Tree Protocol () Administrative Mode for the port or LAG.
For more information about , see “Configuring Spanning Tree Protocol” on
page 243. The possible values for this field are:
• Enable: Enables the Spanning Tree Protocol for this port.
• Disable: Disables the Spanning Tree Protocol for this port.
Admin Mode Use the pulldown menu to select the port control administration state, which
can be one of the following:
• Enable: The port can participate in the network (default).
• Disable: The port is administratively down and does not participate in the
network.
Broadcast Storm Recovery
Mode
Enable or disable this option by selecting one of the following options on the
pulldown entry field:
• Enable: When the broadcast traffic on the specified Ethernet port exceeds
the configured threshold, the switch blocks (discards) the broadcast
traffic.
• Disable: The port does not block broadcast traffic if traffic on the port
exceeds the configured threshold. The factory default is disabled.
Broadcast Storm Recovery
Level
Specify the data rate at which storm control activates. The value is a
percentage of port speed and ranges from 0-100. The factory default is 5
percent of port speed.
Multicast Storm Recovery
Mode
Enable or disable this option by selecting one of the following options on the
pulldown entry field:
• Enable: When the multicast traffic on the specified Ethernet port exceeds
the configured threshold, the switch blocks (discards) the multicast traffic.
• Disable: The port does not block multicast traffic if traffic on the port
exceeds the configured threshold. The factory default is disabled.
Multicast Storm Recovery
Level
Specify the data rate at which storm control activates. The value is a
percentage of port speed and ranges from 0-100. The factory default is 5
percent of port speed.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
