D-Link DWL-8610AP User Manual

Configuring Advanced Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 638
D-Link UWS User Manual
Known Client Configuration
The Known Client Configuration page allows you to add wireless clients to the Known Client Database and
specify the authentication action to take on the client when it attempts to access the network. The database
contains wireless client MAC addresses and names. The database is used to retrieve client descriptive names
from the RADIUS server as well as implement MAC Authentication.
Figure 398: Known Client Configuration
Table 365 describes the fields on Known Client Configuration page.
Command Buttons
The page includes the following buttons:
• Refresh—Updates the page with the latest information.
• Submit—Updates the switch with the values you enter. To retain the new values across a power cycle,
you must perform a save (Tool > Save Changes).
Table 365: Known Client Configuration
Field Description
MAC Address Shows the MAC address of the client. To view or configure the name
or authentication action for another client in the Known Client
database, select its MAC address from the menu.
Name Enter a descriptive name for the client, which can contain up to 32
alphanumeric characters. This field is optional.
Authentication Action Specify the action to take on a wireless client when MAC
authentication is enabled on the network. The following options are
available:
• Grant—Allow the client with the specified MAC address to access
the network.
• Deny—Prohibit the client with the specified MAC address from
accessing the network.
• Global Action—Use the global white-list or black-list action
configured on the Advanced Global Configuration page to
determine how to handle the client.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
