D-Link DWL-8610AP User Manual

Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 137
D-Link UWS User Manual
Reset Configuration
Use the Reset Configuration page to clear IP address bindings between that the DHCP server assigned to the
client.
To access the Reset Configuration page, click LAN > Administration > DHCP Server > Reset Configuration in
the navigation tree.
Figure 59: Reset Configuration
• After you select the bindings or conflicts to clear and, if necessary, enter the specific IP address, click Clear
to remove the binding from the DHCP server.
Table 51: Reset Configuration Fields
Field Description
Clear Specifies what to clear from the DHCP server database:
• All Dynamic Bindings: Deletes all dynamic bindings from all address pools.
• Specific Dynamic Binding: Deletes the specified binding.
• All Address Conflicts: Deletes all address conflicts from the DHCP server
database.
• Specific Address Conflict: Deletes a specified conflicting address from the
database.
Clear IP Address If you select Specific Dynamic Bindings or Specific Address Conflicts from the
Clear field, the screen refreshes and the Clear IP Address field appears. Enter
the specific IP address to clear from the DHCP server.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
