D-Link DWL-8610AP User Manual

AP Management
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 584
D-Link UWS User Manual
Table 342 describes the fields you must complete to upgrade APs.
Table 342: Software Download
Field Description
Server Address Enter the IP address of the host where the upgrade file is located. The host must have a
TFTP server installed and running.
File Path Enter the file path on the TFTP server where the software is located. You may enter up
to 96 characters.
File Name Enter the name of the upgrade file. You may enter up to 32 characters, and the file
extension .tar must be included.
Group Size When you upgrade multiple APs, each AP contacts the TFTP server to download the
upgrade file. To prevent the TFTP server from being overloaded, you can limit the
number of APs to be upgraded at a time.
In the Group Size field, enter the number of APs that can be upgraded at the same time.
When one group completes the upgrade, the next group begins the process.
Image Download
Type
Type of the image to be downloaded, which can be one of the following:
• All images (img_dwl8600, img_dwl3600/6600, img_dwl2600, img_dwl8610,
img_dwl6610, img_dwl6700 and img_dwl8710)
• img_dwl8600
• img_dwl3600/6600
• img_dwl2600
• img_dwl8610
• img_dwl6610
• img_dwl6700
• img_dwl8710
Note: To download all images, make sure you specify the file path and file name for both
images in the appropriate File Path and File Name fields.
Managed AP The list shows all the APs that the switch manages. If the switch is the Cluster Controller,
then the list shows the APs managed by all switches in the cluster.
Note: A managed AP in a transitional state, such as Authenticated, does not appear in
the list and is not eligible for the software download.
Each AP is identified by its MAC address, IP address, and Location in the <MAC - IP -
Location> format. To upgrade a single AP, select its entry. To upgrade all APs, select the
All option. If All is selected, the Group Size field will limit the number of simultaneous
AP upgrades so the TFTP server is not overwhelmed. To select multiple APs to upgrade,
CTRL + click each AP to upgrade.
Note: D-Link recommends that you upgrade all managed APs at the same time.
However if the network includes WDS managed APs, the satellite APs should be
upgraded before the root APs.
After the software download completes and an AP become managed, it reappears in
this list.
Note: A satellite AP that is managed over a WDS link takes longer to become managed
than an AP on the wired network.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
