D-Link DWL-8610AP User Manual

Managing and Viewing Logs
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 118
D-Link UWS User Manual
Event Log
Use the Event Log page to display the event log, which is used to hold error messages for catastrophic events.
After the event is logged and the updated log is saved in flash memory, the switch will be reset. The log can
hold at least 2,000 entries (the actual number depends on the platform and OS), and is erased when an
attempt is made to add an entry after it is full. The event log is preserved across system resets.
To access the Event Log page, click LAN > Monitoring > Log > System Log in the navigation tree.
Figure 45: Event Log
• Click Refresh to update the page with the latest log entries.
Table 39: Event Log Fields
Field Description
Entry The number of the entry within the event log. The most recent entry is first.
Filename The D-Link DWS-4000 Series source code filename identifying the code that
detected the event.
Line The line number within the source file of the code that detected the event.
Task ID The OS-assigned ID of the task reporting the event.
Code The event code passed to the event log handler by the code reporting the
event.
Time The time the event occurred, measured from the previous reset.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
