D-Link DWL-8610AP User Manual

Configuring MLD Snooping Queriers
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 234
D-Link UWS User Manual
Configuring MLD Snooping Queriers
In an IPv6 environment, MLD Snooping requires that one central switch or router periodically query all end-
devices on the network to announce their multicast memberships. This central device is the 'MLD querier'. The
MLD query responses, known as MLD reports, keep the switch updated with the current multicast group
membership on a port-by-port basis. If the switch does not receive updated membership information in a
timely fashion, it will stop forwarding multicast to the port where the end device is located.
These pages enable you to configure and display information on MLD Snooping queriers on the network and,
separately, on VLANs.
MLD Snooping Querier Configuration
Use this page to enable or disable the MLD Snooping Querier feature, specify the IP address of the router to
perform the querying, and configure related parameters. Users must have Read/Write access privileges to
change the data on this page.
To access this page, click LAN > L2 Features> MLD Snooping Querier > MLD Snooping Querier Configuration
in the navigation tree.
Figure 139: MLD Snooping Querier Configuration
Table 123: MLD Snooping Querier Configuration Fields
Field Description
Snooping Querier Admin
Mode
Select the administrative mode for MLD Snooping for the switch from the
pulldown menu. The default is Disable.
Snooping Querier Address Specify the Snooping Querier Address to be used as source IPv6 address in
periodic MLD queries. This address is used when no address is configured on
the VLAN on which query is being sent.
MLD Version Specify the MLD protocol version used in periodic MLD queries.
Query Interval Specify the time interval in seconds between periodic queries sent by the
snooping querier. The Query Interval must be a value in the range of 1 and
1800. The default value is 60.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
