Basic Setup
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 556
D-Link UWS User Manual
The following table describes the fields on the SSID page.
Command Buttons
The page includes the following buttons:
• Refresh—Updates the page with the latest information.
• Submit—Updates the switch with the values you enter. To retain the new values across a power cycle,
you must perform a save on the WLAN switch (not the AP). To perform a save, click Tool > Save Changes.
• Next—Navigates to the next page in the Basic Setup configuration. Any changes you made to the current
page are saved before the next page is displayed. To retain the new values across a power cycle, you must
perform a save on the WLAN switch (not the AP). To perform a save, click Tool > Save Changes.
Table 329: Default VAP Configuration
Field Description
Radio 1
Radio 2
You configure the VAPs for Radio 1 and Radio 2 separately. Select the radio to configure
the settings for before you enable the VAP.
The DWL-3600AP is a single-radio AP. Any settings you configure for Radio 1 (802.11a/n)
are not applied to the DWL-3600AP. If the selected Hardware Type ID for the AP profile is
DWL-3600AP, the radio selectors are not available.
Network Use the option to the left of the network to enable or disable the corresponding VAP on
the selected radio.
When enabled, use the menu to select a networks to assign to the VAP. You can configure
up to 64 separate networks on the switch and apply them across multiple radio and VAP
interfaces. By default, 16 networks are pre-configured and applied in order to the VAPs on
each radio.
Enabling a VAP on one radio does not automatically enable it on the other radio.
Note: You cannot disable the default VAP, VAP0.
Note: The IEEE 802.11n standard prohibits static WEP and dynamic WEP (IEEE802.1X)
security modes. Additionally, 802.11n requires the CCMP(AES) WPA cypher to be enabled.
If the AP profile includes the 802.11n radio mode, you cannot select a configured network
from the Network menu if the network uses static or dynamic WEP as the security method
or if the CCMP(AES) WPA cypher is not enabled.
To configure additional networks, click WLAN > Administration > Advanced Configuration
> Networks.
Edit Click Edit to modify settings for the corresponding network.
When you click Edit, the Wireless Network Configuration page appears.
VLAN Shows the VLAN ID of the VAP. To change this setting, click Edit.
L3 Tunnel Shows whether L3 Tunneling is enabled on the VAP. To change this setting, click Edit.
Note: When L3 tunneling is enabled, the VLAN ID is not used. In fact, the switch puts the
management VLAN ID, if any, on the tunneled packets.
Hide SSID Shows whether the VAP broadcasts the SSID. If enabled, the SSID for this network is not
included in AP beacons. To change this setting, click Edit.
Security Shows the current security settings for the VAP. To change this setting, click Edit.
Redirect Shows whether HTTP redirect is enabled. The possible values for the field are as follows:
• HTTP: HTTP Redirect is enabled
• None: HTTP Redirect is disabled
